Radome Maintenance Stand - Model 15F3510
Radome Maintenance Stand - Model 15F3510
Designed to safely access crown of all narrow body aircraft. Use for planes from 15’ to 25’ platform height.
The adjustable work platform, aircraft maintenance stand is an efficient solution for high and overhead maintenance, construction, manufacturing or production jobs that are 15' to 25' off the ground.
IATA compliant
Not CE compliant
Pricing
| Radome Maintenance Stand - Model 15F3510 | ||||||
|---|---|---|---|---|---|---|
| Model Number | Capacity (lbs.) | Working Height | Platform Size | Weight of Stand (Lbs.) | Dimensions [L x W x H] | Price |
| DS-15F3510 | 500/2500 | 15' - 25' | 48" x 84" | 8,000 | 53" x 128" x 104" | $41,999 |
| Leadtime 14-16 weeks - ships in 3 pieces and has to be shipped on a 53' step deck riser or load leveler | ||||||
Features
Standard Features:
Designed to safely access crown of all narrow body aircraft
Contoured hydraulically adjustable cage to match narrow body fuselage
750 lb. platform capacity, 2,500 lbs. overall
Hydraulically elevates 186.5” to 300”
Double acting hydraulic hand pump with two 2” dia. x 35” stroke lift cylinders, plus an air over hydraulic system
Hydraulic restrictors in case of pressure failure
Safety strut with pins
Non-slip steel grip-strut steps
Two fall arrest anchor points in upper platform
Fixed rear and swivel front casters provide ease in maneuverability
Hand adjustable screw jacks on each corner for stability
Drop down pole to tow stand
16” diameter solid tires
Used for military ground support equipment
All-steel welded construction
Durable epoxy powder coat finish
Note: All products should be inspected frequently to insure safe operation. Final testing and inspection left to end user after final assembly has been completed.
Options
Options:
12 Volt work light package
Safety mesh on contoured cage
Saloon Style entry doors on upper platform
Parts
Please call 1-888-802-3651 for replacement parts
Documentation / Videos
Drawings:
DS-15F3510-Radome-Stand
